Product Details:
Place of Origin: China
Brand Name: Wan Tong
Model Number: GS
Payment & Shipping Terms:
Minimum Order Quantity: 500 square meters
Price: $2.66/square meters 500-4999 square meters
Packaging Details: palletizing
Supply Ability: 10000 Square Meter/Square Meters per Week

SGS Certified Plastic Geocell Gravel Driveway Grid for Enhanced Performance and Safety

Description
Type: Geocells, Geocells Warranty: More Than 5 Years
After-sale Service: Online Technical Support Project Solution Capability: Others
Product Name: Manufacturer Plastic Hdpe Black Geocell Color: Request
Application: Roadbed Reinforcement Thickness: 1.5mm
Surface: Textured Smooth Height: 50mm
Description: Platic Parking Grass Grid Geocell WELDING DISTANCE: 330mm
Certifications: SGS Port: Qingdao Port

HDPE plastic geocell gravel driveway grid  honeycomb gravel grid



WELDING DISTANCE :400mm       High:120mm     Thickness:1.1mm

SGS Certified Plastic Geocell Gravel Driveway Grid for Enhanced Performance and Safety 0

Product Introduction



Geocell is made of a new type of high-strength geosynthetics, which is popular with both domestic and abroad, which welding the strengthened HDPE sheets by the high-power ultrasonic and forming to be a structure of three-dimensional reticular formation. Easily folding and convenient for transportation. When be in construction, the geocell can be pull into a network and launched into a three-dimensional honeycomb grid. As it filled in soil, macadam, concrete or other granular materials, constituted to be a construction, which has strong sidewise restraint and high rate of stiffness.

Product Overviews

SGS Certified Plastic Geocell Gravel Driveway Grid for Enhanced Performance and Safety 1

SGS Certified Plastic Geocell Gravel Driveway Grid for Enhanced Performance and Safety 2

SGS Certified Plastic Geocell Gravel Driveway Grid for Enhanced Performance and Safety 3

Product Function

1.To stable the roadbed of railway.

2.To stable the roadbed of highroad.

3.To bear the load of dike or retaining wall.

4.To the improvement of shallow riverway.

5.To support the pipeline and sewer.

6.For the prevention of landslide by useing geocell as a heavy-duty hybrid force retaining wall

7.To be used as independent wall, wharf and breakwater, etc.

8.For the desert, beaches and the riverbed, the river bank`s regulation.

SGS Certified Plastic Geocell Gravel Driveway Grid for Enhanced Performance and Safety 4SGS Certified Plastic Geocell Gravel Driveway Grid for Enhanced Performance and Safety 5

Specification

Material Properties

Unit









Test Method

Cell Depth

mm

75

100

150

200



Polymer Density

g/cm3

              0.935-0.965

ASTM D 1505

Enviromental Stress Crack Resistance

Hours

                >400

ASTM D 5397

Enviromental Stress Crack Resistance

Hours

                  6000

ASTM D 1693

Carbon Black Content

%

                >1.5

ASTM D 1603

Nominal Sheet Thickness Before Texturing

mm

            1.27 -5%,+10%

ASTM D 5199

Nominal Sheet Thickness After Texturing

mm

            1.52-5%,+10%

ASTM D 5199

Strip Puncture Resistance

N

                450

ASTM D 4833

Seam Peel Strength

N

1065

1420

2130

2840

EN ISO13426-1B

Seam Efficiency

%

100

GRI-GS13

Nominal Expanded Cell Size (width x length)

mm

320x287,475x508 etc



Nominal Expanded Panel Size (width x length)

 m

2.56x8.35, 4.5x5.0, 6.5x4.5, 6.1x2.44





Certifications

SGS Certified Plastic Geocell Gravel Driveway Grid for Enhanced Performance and Safety 6

we have obtained ISO9001 certificate SGS certificate and CE certificate. Our products are widely applied in many fields, such as road, highway, airway, coal mine, water and soil conservation, water conservancy and basic construction.
