Product Details:
|
| Warranty: | NONE | After-sale Service: | Online Technical Support, Onsite Inspection |
|---|---|---|---|
| Project Solution Capability: | Graphic Design, Cross Categories Consolidation | Application: | Hotel, Hospital, School, Leisure Facilities, Water Conservancy |
| Geotextile Type: | Non-Woven Geotextiles | Type: | Geotextiles |
| Name: | Non Woven Geotextile Type Geo Bag | Color: | Requirement |
| Material: | PP(polypropylene) PET (polyester) | Length: | 50-100m/roll (at Request) |
| Width: | 1-6m | Weight: | 100-1000g/sqm |
| Usage: | Ecological Slope Protection System | Keyword: | Geotextile Bag Fabric Grow Bags Geobag |
| Port: | Any Port Of China |
geotextile planting grow bags Non woven geotextile type geo bag used for reservoir lake
geotextile bag fabric grow bags geobag
Geotextile bags that component is PP or PET needle punched non woven fabric.
It is a greener environmental protection solutions used for erosion control, embankment or slope protection and shoreline stabilization, stormwater management, and the creation of rain gardens and other functional green spaces.A lot of geotextile bags build into a huge vegetated walls.Then the walls are planted with the native plants, soli and seeds.Within weeks,the plants grow through the bags and develop extensive root systems that lock into the native soil and form an ecological sound vegetated erosion control system with permanent structural strength.
Product Application:
1.Ecohydraulic Engineering:
Natural environment for both sides of the ecological river,soil and water conservation,reservoir fluctuation zone regreening, wetland project, coastal engineering etc.
2.Highway Engineering:
Roadbed side slope,retaining wall project, massif excavate side slope,bridgepier slope protection,culvert exits and entrances "Eight word" wall,sound protective screen, ecological isolation strip,swelled ground side slope,freeze thawing district side slope etc.
3.Railway Engineering:
Roadbed side slope,retaining wall project, massif excavate side slope,bridgepier slope protection,culvert exits and entrances "Eight word" wall,ecological beauty spot ecological district side slope,ecological fragile district ecological side slope etc.
4.Municipal garden engineering:
Massif regreening,massif excavate side slope,urban center ecological river bank,pack lakeshore,puente hills landfill,mine regreening,golf course,gardening landscape wall,
saline-alkali soil side slope etc.
5.Real estate landscape engineering:
Artificial landscape riverway,uptown side slope,gardening landscape wall,hydrophile retaining wall,roof greening ,etc
6.Others:
Slope body collapsed emergency manage,desert greening,natural reserves,the coast protection embankment,storage place,flood protection wall,ecological vertical wall etc.
Features
1. With the advantages of anti-UV, anti-aging, non-toxic, no combustion-supporting, bag rip no stretch;
2. Bags are soft with good integral, permeability is strong and scouring resistance, good durable performance;
3. Good plasticity and construction process is simple;
4. Strong corrosion resistance, resistance to microbes, high s oil stability, easy for plant growth;
5. Comprehensive functions of environmental protection, ecological afforestation, soil and water conservation, forming of ecological slope protection system.
Specification
| PROPERTIES | TEST METHOD | UNIT | MINIMUM AVERAGE VALUE | ||||
|
|
|
| MWG270 | MWG370 | MWG570 | MWG665 | MWG770 |
| Tensile Strength , MD | ASTM D 4595 | kN/m | 38.5 | 52.5 | 70 | 70 | 105.1 |
| Tensile Strength , CD | ASTM D 4595 | kN/m | 35.9 | 47.3 | 70 | 96.3 | 84 |
| Elongation, MD | ASTM D 4595 | % | 25 | 25 | 25 | 25 | 25 |
| Elongation, CD | ASTM D 4595 | % | 25 | 25 | 25 | 25 | 25 |
| Tensile Strength at |
|
|
|
|
|
|
|
| 2%, MD | ASTM D 4595 | kN/m | 7 | 11 | 14 | 17.5 | 21 |
| 2%, CD | ASTM D 4595 | kN/m | 8.6 | 12.3 | 19.3 | 25 | 22.8 |
| 5%, MD | ASTM D 4595 | kN/m | 17.7 | 21.9 | 35 | 35 | 52.5 |
| 5%, CD | ASTM D 4595 | kN/m | 19.8 | 22.8 | 39.4 | 53 | 47.1 |
| Factory Seam Strength | ASTM D 4884 | kN/m | 18.4 | 25.1 | 37.5 | 52.5 | 43.8 |
| Apparent Opening Size | ASTM D 4751 | mm | 0.6 | 0.43 | 0.6 | 0.43 | 0.6 |
| Permittivity | ASTM D 4491 | sec-1 | 0.7 | 0.9 | 0.4 | 0.26 | 0.04 |
| Water Flow Rate | ASTM D 4491 | l/min/m2 | 2037 | 1630 | 1222 | 815 | 611 |
| UV Resistance (% retained after 500 hours) | ASTM D 4355 | % | 80 | 80 | 80 | 70 | 80 |
We are willing to supply good quality products and good service to satisfy customer's need.
1.Which payment do you accept?
For you convinience,our payment can be L/C,TT,Westunion,paypal
2.Are you willing to provide the samples?
We are glad to provide the samples to you if we have the identical or similar samples in our warehouse.
3.May I get a cheaper price?
A favorable discount will be given if there is a large quantity you need.
4.Do the customized designs be accepted?
Yes, we welcome customized designs.
5.How to contact with us?
Choose one product and leave a message there, or see the contact way, there are the contacted detail information.
