Product Details:
|
| Type: | Geogrids | Warranty: | NONE |
|---|---|---|---|
| After-sale Service: | Online Technical Support, Onsite Installation, Onsite Training, Onsite Inspection, Free Spare Parts | Project Solution Capability: | Graphic Design, 3D Model Design, Total Solution For Projects, Cross Categories Consolidation |
| Application: | Road Construction, Roadbed | Design Style: | Chinese |
| Color: | Normal Black ,white, Yellow Etc., | Product Name: | Geogrid |
| Name: | Roadbed Solidification Biaxial Polyester 80-80 PET Geogrid | Length: | 50-200m |
| Width: | 1m-6m | Standard: | ISO Standard |
| Keyword: | Roadbed Solidification Biaxial Polyester 80-80 PET Geogrid | Thickness: | 0.2mm-4mm |
Property | Test Method | TGSG15-15 | TGSG20-20 | TGSG30-30 | TGSG40-40 | |||||
Ultimate Tensile Strength(1)(KN/M) | MD | ASTM D6637 | 15 | 20 | 30 | 40 | ||||
CD | 15 | 20 | 30 | 40 | ||||||
Elongation at Maximum Load(%) | MD | 13 | ||||||||
CD | 13 | |||||||||
Tensile Strenght at 2% Elongation(KN/M) | MD | 5 | 7.5 | 10.5 | 14 | |||||
CD | 5 | 7.5 | 10.5 | 14 | ||||||
Tensile Strenght at 5% Elongation(KN/M) | MD | 7 | 14 | 21 | 28 | |||||
Tensile Strenght at 5% Elongation(KN/M) | CD | 7 | 14 | 21 | 28 | |||||
Mininmum | % | ASTM4218 | 2 | |||||||
Roll Length(M) | 100/75/50 | |||||||||
Roll Width(M) | 2/3.9/3.95/5/5.9/6 | |||||||||
