Product Details:
|
| Type: | Geogrids | Warranty: | NONE |
|---|---|---|---|
| After-sale Service: | Online Technical Support, Onsite Installation, Onsite Training | Project Solution Capability: | Total Solution For Projects |
| Application: | Road, Road Construction | Design Style: | Traditional |
| Raw Material: | Plastic PP | Name: | High Tensile Soil Reinforcement Slope Protection Polypropylene Geogrid |
| Color: | Black | Length: | 50-100m |
| Certificate: | CE /ISO9001 | Tensile Strength: | 20-20kn 30-30kn 40-40kn 50-50kn 70-70kn 100-100kn |
| Width: | 1-6m | MESH SIZE: | 12.7*12.7mm. 25.4*25.4mm |
| HS Code: | 3926909090 | Port: | Any |
Property | Test Method | TGSG15-15 | TGSG20-20 | TGSG30-30 | TGSG40-40 | |||||
Ultimate Tensile Strength(1)(KN/M) | MD | ASTM D6637 | 15 | 20 | 30 | 40 | ||||
CD | 15 | 20 | 30 | 40 | ||||||
Elongation at Maximum Load(%) | MD | 13 | ||||||||
CD | 13 | |||||||||
Tensile Strenght at 2% Elongation(KN/M) | MD | 5 | 7.5 | 10.5 | 14 | |||||
CD | 5 | 7.5 | 10.5 | 14 | ||||||
Tensile Strenght at 5% Elongation(KN/M) | MD | 7 | 14 | 21 | 28 | |||||
Tensile Strenght at 5% Elongation(KN/M) | CD | 7 | 14 | 21 | 28 | |||||
Mininmum | % | ASTM4218 | 2 | |||||||
Roll Length(M) | 100/75/50 | |||||||||
Roll Width(M) | 2/3.9/3.95/5/5.9/6 | |||||||||
