High Strength 40kn/M HDPE Uniaxial Plastic Geogrid for 50m Roll Length and 1m Width

Large Image : High Strength 40kn/M HDPE Uniaxial Plastic Geogrid for 50m Roll Length and 1m Width

Product Details:

Place of Origin:	Shandong, China
Brand Name:	Wantong

Payment & Shipping Terms:

Minimum Order Quantity:	1000 square meters
Price:	$0.16 - $1.80/square meters
Supply Ability:	10000 Square Meter/Square Meters per Day

Contact Now

High Strength 40kn/M HDPE Uniaxial Plastic Geogrid for 50m Roll Length and 1m Width

Description

Type:	Geogrids	Warranty:	NONE
After-sale Service:	Online Technical Support	Project Solution Capability:	Graphic Design
Application:	Outdoor	Design Style:	Asian
Color:	Black	Application:	Retaining Wall, Steep Slop, Dam, Road Base
Material:	HDPE PP	Certificate:	CE
MOQ:	1000 Square Meter	Roll Width:	1m
Roll Length:	50m	HS Code:	3926909090
Transport Package:	Woven Bag And Poly Bag	Keywords:	Uniaxial Geogrid
Port:	Qingdao

Product Description

40kn/M HDPE Uniaxial Plastic Geogrid

Uniaxial plastic technical grid is a kind of technical material with high strength that
uses high molecular polymer as main raw material, adds certain ultraviolet proof and aging resistance agent and makes messy chain shape molecules have drectional layout and from linear status by unidirectional extension. Plastic technical grid makes directional tension under certain temperature condition according to physical features of high molecule polymer,so its strength is very high in tension direction, tension resistance reaches 100-200 Mpa,yield elongation rate is only 4-10%, it is near to the level of low carbon steel and much better than traditional or current reinforcement materials, and is very ideal synthetic material for strengthening and reinforcement of civil projects.

Specification

uniaxial geogrid（PP）Technical Parameter (GB standard)
Item	Specification
Type	TGDG 35	TGDG 50	TGDG 80	TGDG110	TGDG 120	TGDG150	TGDG200	TGDG260	TGDG 300
Tensile Strength≥（KN/M）	35	50	80	110	120	150	200	260	300
Maximum elongation≤（%）	10
Tensile strength at 2% elongation≥（KN/M）	10	12	26	32	36	42	56	94	108
Tensile strength at 5% elongation≥（KN/M）	22	28	48	64	72	84	112	185	213

uniaxial geogrid（PE）Technical Parameter (GB standard)
Item	Specification
Type	TGDG 50	TGDG 80	TGDG100	TGDG110	TGDG120	TGDG 150	TGDG 170	TGDG 200	TGDG 220
Tensile Strength≥（KN/M）	50	80	100	110	120	150	170	200	220
Maximum elongation≤（%）	10
Tensile strength at 2% elongation≥（KN/M）	12	21	26	29	38	41	52.5	60	64
Tensile strength at 5% elongation≥（KN/M）	23	40	50	55	75.5	81	103	110	127

APPLICATION

40kn/M HDPE Uniaxial Plastic Geogrid

1. Pavement subgrade stabilization
2. Area /Ground stabilization
3. Pavement base reinforcement
4. Working & load transfer platforms
5. Rail Track-bed stabilization
6. Reinforced granular foundation beds

Packing & Delivery

* Used in the various environments.
* UV stabilized.
* Used with variety of materials, including soil and concrete.
* Resistance to the low temperature. It can be used in the minus 45 degrees to 50 degrees.
* Resistance to the long term chemical or biological degradation.
* High stability and bearing capacity to increase service life.
* High tensile loads in the transverse direction.
* Prevent the material loss caused by the roadbed distortion and crack.
* Lightweight for quick installation and low construction cost.

Company Profile

Taian Wantong Composite Material Co.,Ltd is located in Taian city, Shandong province, which adjacent to Jinan International Airport and Taian High Speed Rail Station, enjoying convenient in transportation. Our factory is located in the middle of China's most developed transport network, by high speed train only takes 2 hours to reach Beijing and 3 hours to reach Shanghai Taian Wantong Composite Material Co.,Ltd pays attention to customer interests and public interest and uses good faith for the operating principles. We are high-tech enterprises specialized in geotechnical composite materials research, development and production. We are China Geosynthetics Association governing units. We establish a good relationship with many universities and engineering companies. Taian Wantong Composite Material Co.,Ltd has been dedicated in R&D, production, sales and installation services of geosynthetics for many years.Our main products including fiberglass geogrid, warp knitted polyester geogrid, uniaxial plastic geogrid, biaxial plastic geogrid, steel plastic composite geogrid, warp knitted composite geogrid, , geotextile, HDPE geomembrane, LDPE geomembrane, EVA geomembrane, composite geomembrane, fiberglass-polyester paving mat, high-performance polyester cloth , three-dimensional geomat, geonet, geocell, industrial fiber, soft water pipe, geocomposite dreinage systems(GDS),geosynthetic clay Liners, and so on. The products are widely used in highway, railway, airport, wharf, coal mine, water conservancy, electric power, water and soil conservation, circumstance afforestation and fundamental construction, which are got high comments from engineering experts and clients. Through strong company strength, high-quality products and good service for customers, Taian Wantong Composite Material Co., Ltd becomes the leader in China geosynthetics field. We wish to cooperate sincerely with friends at home and abroad, paint the grand blueprint and create brilliance together.

FAQ

1. How long have you been in the Geo-synthetics and fiberglass product industry?
----Since 2007 years.
2. Are you manufacturer or trad company
-----We are the manufacture specialized in Geo-synthetics and fiberglass product, in Taian city, ShanDong Province, China.
3.How much the transportation freight of sample?
------The freight depends on the weight and packing size and destination from here to your location.
4. How long can I expect to get the sample?
------The samples will be ready for delivery in 3-5days. The samples will be sent via international express such as DHL, TNT, and EMS would be arrived within 3-5 days.
5. Can we have our LOGO or company name to be printed on your products or package?
------Sure, Your LOGO could be printed on your product by Hot stamping, Printing, Embossing, UV coating, Silk-screen Printing or Sticker.
6. Do you have stock?
------Most of product are under regular production, we can make delivery immediately if we the specific one in stock.

OUR SERVICES

Quality assurance
1. On a regular basis or as per your request,we entrust national testing agencies to conduct quality inspections
2.Strictly in accordance with the ISO9001-2008 international quality system standard,we monitor and manage the whole process throughout production,quality testing,and measurement to ensure product quality
3. For quality-related construction delay or substandard construction(except for damage or losses due to customer’s responsibility or irresistible natural disasters),we have refunding,replacement,and repair services.We will respond to customers’ feedbacks on quality issues within 24 hours.
